HDMI™ 8×1 4K switcher 4K@60Hz 4:4:4 let a display or projector with eight HDMI™-enabled video Sources

INTRODUCTION

The HDMI™ 8×1 4K switcher 4K@60Hz 4:4:4 let a display or projector with four HDMI™-enabled video sources. This switch has eight independent HDMI ports ™ And USB 2.0 B input, each HDMI ™ Supports 4K resolution and 7.1 surround sound audio, as well as two or four USB 2.0 A ports for connecting devices that support USB 2.0. It has two USB-A ports for keyboard and mouse, and two USB 2.0 A ports for output, allowing customers to operate on eight USB/HDMI ports ™ A pair of keyboards, mice, and other USB 2.0 devices are shared between the PC and the device. You will be amazed at how this video switch maintains ultra-high definition picture quality. The latest A/V devices support 4K, with a resolution four times that of 1080p. In addition, as the switch is backward compatible with high-definition 1080p, you can rest assured that any video source will look great in your digital signage application. Enjoy worry free operation through two switching modes: manually switch ports through the front panel buttons or switch through keyboard hotkeys.

FEATURES

• Supports two USB-A ports for USB keyboards and mice, and two USB 2.0 A ports for other USB devices up to 480Mbps.
• Support manual switching: front panel buttons or keyboard hotkeys, serial port RS232 switching, remote control switching.
• Support digital display switching ports and status
• Support EDID emulator function
• Support full 3D video format
• Support up to 4K@60Hz 4:4:4
• Supports HDCP2.3, HDCP 2.2 and HDCP 1.4
• Supports high dynamic range (HDR) videos
• Support consumer electronics control
• Supports the highest data transmission rate, up to 6.0Gbps per channel (18Gbps for all channels)
• TMDS clock can reach 600MHz
• Support 12 bits per channel (36 bits for all channels) dark color
• Support uncompressed audio such as LPCM
• Support DTS, Dolby Digital (including DTS-HD Master audio) ™ Compressed audio such as Dolby TrueHD

SPECIFICATIONS
