HDMI™ 2×1 Switcher Supports 4K@60Hz 4:4:4, MIC, speaker, USB device, keyboard and mouse Function

Package Content

INTRODUCTION

The HDMI™ 2×1 4K switcher 4K@60Hz 4:4:4 lets a display or projector with two HDMI™-enabled video sources. The switch features two independent HDMI™ and USB-B inputs that each HDMI™ supports 4K resolution and 7.1 surround sound audio and a USB port to connect a PC. It features three USB-A ports for Keyboard, mouse, USB device, and mic in and audio out function, which allows the customers to share a pair of Keyboard, mouse, and other USB device between two USB/HDMI™ PCs and devices. You’ll be amazed at how this video switch maintains Ultra HD picture quality. 4K is supported by the latest A/V devices and delivers four times the resolution of 1080p. Plus, because the switch is backward compatible with high-definition 1080p, you can rest assured any video source will look great in your digital signage application. Enjoy hassle-free operation with two switching modes: Manual port switching via the front panel button or hotkey switching via the keyboard.

FEATURES
  • Support three USB-A ports for USB keyboard, mouse and other USB device.
  • Support mic in and stereo audio out function with an on/off button control and LED indicator.
  • Support manual switching: front panel button or hotkey switching via the keyboard.
  • Support full 3D video format.
  • Support high resolution up to 4K@60Hz YUV 4:4:4
  • Support HDCP 2.2 and HDCP 1.4.
  • Support High Dynamic Range (HDR) video.
  • Support Consumer Electronics Control.
  • Support highest data transfer rate up to 6.0Gbps per channel (18Gbps all channels).
  • TMDS clock can be up to 600MHz.
  • Support 12bit per channel (36bit all channels) deep color.
  • Support uncompressed audio such as LPCM.
  • Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD).
SPECIFICATIONS
Input Ports

  • HDMI x 2, USB x 2, MIC x 1

Output Ports

  • HDMI x 1, Keyboard x 1, Mouse x 1, USB device x 1, Audio x 1

Vertical Frequency Range

  • 50/60Hz

Video Amplifier Bandwidth

  • 6.0Gbps/600MHz per channel(18Gbps all channels)

Interlaced(50&60Hz)

  • 480i, 576i, 1080i

Progressive(50&60Hz)

  • 480p, 576p, 720p, 1080p, 4K@24/25/30/50/60Hz

Limited Warranty

  • 1 Year Parts and Labor

Operating Temperature

  • 0℃ to 50℃

Storage Humidity

  • 5% to 80% RH non-condensation

Power Supply

  • DC 5V

Power Consumption (Max)

  • 5W

Switcher Unit Cert

  • FCC, CE, RoHS

Dimension(LxWxH)

  • 143x68x23mm

Net Weight

  • 230g

Material

  • Metal

User Manual

  • English Version

Note: Specifications are subject to change without notice.
