USB-B 2.0 HDMI 2×1 KVM Switch Supports (HDMI 4K@60Hz In +USB-B 2.0 Host In) x2 with USB-A 1.1 x2 for Keyboard/ Mouse, Out Wired Remote Control and Hotkey Switch

INTRODUCTION

The USB HDMI KVM Switch supports two HDMI 4K@60Hz inputs and two USB-B host inputs. It allows users to share a keyboard, mouse, and other compatible USB peripherals between two computers while switching between their HDMI video sources.The switch supports video resolutions up to 4K@60Hz and up to 7.1-channel audio pass-through. It provides two USB Type-A 1.1 ports for connecting a keyboard and mouse. Users can switch between the two connected computers using the front-panel SELECT button, hotkey commands, or the wired remote control.

FEATURES

• Supports two PC inputs, each with one HDMI input and one USB-Type B 2.0 host port
• Supports two USB Type-A 1.1 ports for connecting a keyboard and mouse and for hotkey control. USB 2.0 and higher-speed USB devices are not supported
• Supports manual switching via the top-panel button, hotkey switching via the keyboard, or the wired remote control
• Support full 3D video format
• Support high resolution up to 4K@60Hz YUV 4:4:4
• Support HDCP 2.3, HDCP 2.2 and HDCP 1.4
• Support High Dynamic Range (HDR) video
• Support Consumer Electronics Control (CEC)
• Support highest data transfer rate up to 6.0Gbps per channel (18Gbps all channels)
• TMDS clock can be up to 600MHz
• Support 12bit per channel (36bit all channels) deep color
• Support uncompressed audio such as LPCM
• Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD)

SPECIFICATIONS
