HDMI™ 4 x 1 Switcher Supports 4K@60Hz 4:4:4 with Audio Extractor, Remote, RS-232, EDID and WEB GUI TCP/IP Control

Package Content


The HDMI™ 4K @60Hz switcher 4×1 lets you share an HDMI™ display or projector with four HDMI-enabled audio/video source devices. With support for Ultra HD (4K@60Hz), the HDMI™ switcher ensures astonishing picture quality. The 4K@60Hz switcher is also backward compatible with previous HDMI™ revisions, supporting 4K@30Hz /1080p / 720p HDMI™ video resolution devices. Even if you don’t require 4K video today, the HDMI™ 4K Switcher 4×1 ensures you’ll be ready to take advantage of tomorrow’s display technology. It features EDID management for bypassing EDID and fifteen default EDID modes to meet the needs of different display occasions. It also supports audio extract from HDMI source to optical and analog out.

  • Support full 3D video format.
  • Support high-definition resolution 4K@60Hz 4:4:4.
  • Support 600MHz/6Gbps per channel (18Gbps all channels) bandwidth.
  • Support 12bit per channel (36bit all channels) deep color.
  • Support HDCP2.2 and HDCP1.4.
  • Support Dynamic Range (HDR) video.
  • Support Consumer Electronics Control function.
  • Support uncompressed audio such as LPCM.
  • Support Auto-Switching and Audio De-embedding.
  • Support control: Front panel button, optical IR, RS232 via Micro USB port and included adapter cable.
  • Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD).
  • Support EDID management: Internal library with 15 internal EDID handshakes including 4K with HDR in addition to native EDID data copied from the output/display.
  • Support button control, remote control and RS232 control and WEB GUI control.
Input Ports

  • HDMI x 4

Output Ports

  • HDMI x 1, SPDIF x 1, 3.5mm x 1

Vertical Frequency Range

  • 50/60Hz

Video Amplifier Bandwidth

  • 6Gbps/600MHz per channel(18Gbps all channels)


  • 480i, 576i, 1080i


  • 480p, 576p, 720p, 1080p, 4K@24/30//50/60Hz

Limited Warranty

  • 1-Year Parts and Labor

Operating Temperature

  • 0℃ to 70℃

Storage Humidity

  • 5% to 90% RH non-condensation

Power Supply

  • DC 5V 1A

Power Consumption (Max)

  • 5W

Splitter Unit Cert

  • FCC, CE, RoHS

Power Supply Cert

  • FCC, CE, RoHS

Power Adapter Standard

  • US, EU, UK, AU Standard etc.


  • 212.5*101.5*42mm

Net Weight


Note: Specifications are subject to change without notice.
