HDMI™ 4×2 Matrix Support 4K@60Hz 4:4:4 with Downscaler, Dual-way Audio and Audio Return Channel and EDID Control

Package Content


The 4K HDMI™ Matrix Switch lets you share up to 4 distinct HDMI™ or DVI inputs (using HDMI™ to DVI adapters – not included), with audio function, between 2 independent displays or projectors. This matrix switch allows each input and the corresponding audio switching individually, meaning that two different A/V input sources can be shown on each output, or a single source can be output to two, offering maximum flexibility. The switcher features a front panel LED light for easy status monitoring, plus a wireless IR Control for simple control from a distance. Ideal for connecting/switching multiple sources in data centers, help desks, and video broadcasting Facilities, Perfect for digital signage applications in retail environments requiring more than one media player.

  • Support audio output simultaneously: Stereo and Toslink.
  • Audio channels are select-able via remote control.
  • Support downscale function means the product can downscale the input 4K resolution to 1080p by the FHD (1080p) displays and 4K resolution to the 4K displays in the 1×2 splitter mode simultaneously.
  • Supports highest video resolution up to 4K@60Hz YUV 4:4:4.
  • Support High Dynamic Range (HDR) video.
  • Support dual-way audio extractor for both output A and output B.
  • Support Audio Return Channel (ARC), only output A ports supports ARC function.
  • Support HDCP2.2 and HDCP1.4.
  • Supports 600MHz/6Gbps per channel (18Gbps all channels) bandwidth.
  • Supports 12 bit per channel (36bit all channels) deep color.
  • Supports uncompressed audio such as LPCM.
  • Support compressed audio such as DTS, Dolby Digital (including DTS-HD Master Audio™ and Dolby TrueHD).
  • Support Full 3D.
  • Support EDID control (management) function.
Input Ports

  • HDMI x 4

Vertical Frequency Range

  • 50/60Hz

Video Amplifier Bandwidth

  • 6.0Gbps/600MHz per channel(18Gbps all channels)


  • 480i, 576i, 1080i


  • 480p, 576p, 720p, 1080p, 4K@24/30Hz, 4k@50/60Hz

Limited Warranty

  • 1 Year Parts and Labor

Operating Temperature

  • 0℃ to 70℃

Storage Humidity

  • 5% to 90% RH non-condensation

Power Supply

  • 5V DC

Power Consumption (Max)

  • 5W

Matrix Unit Cert

  • FCC, CE, RoHS

Power Supply Cert

  • FCC, CE, RoHS

Power Adapter Standard

  • US, EU, UK, AU Standard etc.


  • 171x61x20mm

Net Weight

  • 245g


  • Metal

User Manual

  • English Version

Note: Specifications are subject to change without notice.
