HDMI™ 4×4 Matrix with Quad Multi-viewer with Seamless Switcher and 2×2 Video Wall Supports 4K@60Hz 4:4:4 with 4 Ways Audio Embedded(3pin Analog Audio), Audio Extractor(Optical and 5Pin Unbalance Audio) ,4 Ways IR In and Out, OLED Display, Touch Panel Switch, Web Gui Control and RS232 Control

INTRODUCTION

The HDMI 4×4 Matrix with Quad Multi-viewer with Seamless Switcher and 2×2 Video Wall lets you share up to 4 distinct HDMI or DVI inputs (using HDMI to DVI adapters – not included), with audio extractor(4 ways optical and stereo out) between 4 independent displays or projectors. This matrix switch features matrix/multi-viewer/video wall mode fits customers different needs allows each input and the corresponding audio to be switched individually as matrix mode, meaning that different four A/V sources can be shown on each output; multi-viewer mode to allow four input source show at a monitor simultaneously, video wall mode to allow a single source can be output to four displays to combination a big size display, offering maximum flexibility. The Matrix switcher features a front panel OLED display for easy status monitoring, plus a front panel Touch Keys control/IR control/RS232 control/WEB GUI control for multiple control method from a distance. Ideal for connecting/switching multiple sources in data centers, help desks and video broadcasting Facilities, Perfect for digital signage applications in retail environments requiring more than one media player.

FEATURES

• Support audio output simultaneously: Optical and Balanced (5pin Phoenix L+/L-/GND/R+/R-) audio
• Support four ways analog audio embedded in
• Support four IR in and IR out matrix switch
• Support OLED display mode and status
• Support multiplexed HDMI 4-input and 4-output
• Support up to 4K@60Hz high definition resolution
• Support three video mode: 4 by 4 matrix switch, 4 by 4 quad multi-viewer, seamless switch (with same resolution) and 2×2 video wall function
• Support scaler up, scaler down function.
• Support multi output resolution 1080p/1600P/4K@30Hz/4K@60Hz
• Support HDCP2.3, HDCP 2.2 and HDCP 1.4
• Support digital audio format LPCM/AC3/DTS.
• Support the highest data transmission rate, up to 6.0Gbps per channel (18Gbps for all channels) TMDS clock can reach 600MHz
• Support 12 bits per channel (36 bits for all channels) deep color
• Support manual control, IR remote control,front Touch Keys control, WEB GUI Control and RS232 control

SPECIFICATIONS
