INTRODUCTION
The Smart Controller for HDMI over IP series provides central management and real time monitoring over the IP based AST transmitters and receivers. With high expandability, a single can serve up to 1024 transmitters and unlimited receivers at once. An intuitive web-based GUI enables users to drag and drop any source to any display, and build video wall, create custom OSD. Plus, provides continuous system monitoring, self-recovery along with real-time event notifications and alerts. Via cooperate network connection, users can remotely access and activate the system from mobile devices.
FEATURES
- Control center of the IP-based Transmitter and Receiver (EX-57EM/EX-57EM-W)
- Monitors all devices in one central system
- Cost effective solution for IoT
- Intuitive and powerful user interface
- Includes Web interface and mobile support
- Easy installation with auto-detection of transmitter and receiver units in the network.
- Drag-and-drop easy matrix switching
- Easy to create multiple video walls
- Allows to create custom OSD
- Watch-dog with self-recovery
- Assigns the video sources for each display with account/password submit
- Supports video wall function
SPECIFICATIONS
Role of usage
- Smart Controller
Input
- 1x RJ-45
Output
- 1x HDMI
HDMI connector
- Type A [19-pin female]
RJ-45 connector
- WE/SS 8P8C
Housing
- Metal enclosure
Model
- 90 x 78 x 29mm [3.5″ x3″ x1.1″]
Package
- 198 x 137 x 74mm [7.8″ x 5.4″ x 2.9″]
Carton
- 420 x 400 x 300mm [1’4″x 1’3″ x 11.8″]
Model
- 222g[0.5 lbs]
Package
- 493g [1 lbs]
Fixedness
- Wall-mounting case with screws
Power supply
- 5V DC
Power consumption
- 3.5 Watt [max]
Operation temperature
- 0~40°C [32~104°F]
Storage temperature
- -20~60°C [-4~140°F]
Relative humidity
- 20~90% RH [no condensation]
Note: Specifications are subject to change without notice.
