HDMI™ Audio Embedder Supports 4K@60Hz 4:4:4

Package Content


The HDMI™ Audio Embedded Converter Supports 4K@60Hz 4:4:4 and can embed audio signals from digital optical or analog stereo Line audio to HDMI™ output. Further, both input and output HDMI™ support video resolution up to 4K@60Hz 4:4:4. It supports High Dynamic Range (HDR) signal pass-through and HDMI™ high-resolution digital audio formats bypass, LPCM 2CH, Dolby TrueHD, Dolby Digital Plus, Dolby Atoms and DTS-HD Master Audio, audio sampling rate up to 192 kHz. HDCP 2.2 and CEC bypass are supported.

  • Embeds multi-channel optical (SPDIF) or Line analog audio to HDMI output.
  • Support 12-bit Deep Full HD, Full 3D, and 4K@60Hz YUV 4:4:4.
  • Support Optical audio supports LPCM 2CH, Dolby Digital 2/ 5.1CH, DTS 2/5.1CH.
  • Support Analog audio supports PCM2.0.
  • Support HDCP2.2.
  • Support High Dynamic Range (HDR) video.
  • Support Consumer Electronics Control function.
  • Support HDMI output audio format: DTS-HD Master Audio™ / Dolby TrueHD.
  • Support 600MHz/6Gbps per channel (18Gbps all channels) bandwidth.
  • Support 12bit per channel (36bit all channels) deep color.
Input Ports

  • HDMI x 1, 3.5mm x 1, Optical x 1

Output Ports

  • HDMI x 1

Vertical Frequency Range

  • 50/60Hz

Video Amplifier Bandwidth

  • 6.0Gbps/600MHz per channel(18Gbps all channels)


  • 480i, 576i, 1080i


  • 480p, 576p, 720p, 1080p, 4K@24/30Hz, 4K@50/60Hz

Limited Warranty

  • 1 Year Parts and Labor

Operating Temperature

  • 0℃ to 70℃

Storage Humidity

  • 5% to 90% RH non-condensation

Power Supply

  • DC 5V

Power Consumption (Max)

  • 5W

Splitter Unit Cert

  • FCC, CE, RoHS

Power Supply Cert

  • FCC, CE, RoHS

Power Adapter Standard

  • US, EU, UK, AU Standard etc.


  • 88×59.5x23mm

Net Weight

  • 126g


  • Metal

User Manual

  • English Version

Note: Specifications are subject to change without notice.
