USB-C™ to Dual HDMI™ 4K@60hz(4:4:4) HDR Adapter Windows supports both SST and MST mode/ OS only supports SST mode

Package Content

INTRODUCTION

This USB 3.1 Type-C™ to HDMI™ + HDMI™ adapter 4K@60Hz 4:4:4 lets you output two HDMI™ video and audio from a USB 3.1 Type-C™ device such as a MacBook, MacBook Pro, Lenovo YOGA or ChromeBook Pixel™ laptop. It lets you utilize a versatile USB 3.1 Type-C™ port on your portable device. USB 3.1 Type-C™ is a reversible connector, so it doesn’t matter which way you plug it in, the adapter will always work, saving you the hassle and embarrassment of fiddling with your device when you’re trying to deliver a presentation.
The adapter lets you harness the video capabilities built into your USB 3.1 Type-C™ connection, to deliver the astonishing quality of Ultra HD to your 4K display. Plus, the adapter is backward compatible with 1080p displays, which makes it a great accessory for home, office, or other workspace applications.
This USB 3.1 Type-C™ video adapter is highly portable for a lightweight design, the perfect accessory for your MacBook, MacBook Pro, Lenovo YOGA, or Chromebook Pixel™, fitting easily into your laptop bag or carrying case.
Note: Your USB-C™ equipped device must support video to work with this adapter.

FEATURES
  • Supports UHD video resolutions up to 4K@60Hz 4:4:4 for single or dual displays (needs your USB-C devices to support 8K resolution output and enough bandwidth).
  • Supports MST functions allowing for extended, mirrored, or duplicated screens with HDR 10, 3D, DSC (Display stream compression), and 7.1 channel audio.
  • Built-in USB Type C cable can be connected directly to your source device.
  • Compatible with Thunderbolt 3.
  • Compatible with DP1.4 alt mode.
  • Compact design with aluminum alloy + ABS.
  • Plug and play with no driver or software installation at all.
SPECIFICATIONS
Input Ports

  • USB-C Male

Output Ports

  • HDMI x 2

Vertical Frequency Range

  • 50/60Hz

Video Amplifier Bandwidth

  • 6.0Gbps/600MHz per channel(18Gbps all channels)

Interlaced(50&60Hz)

  • 480i, 576i, 1080i

Progressive(50&60Hz)

  • 480p, 576p, 720p, 1080p, 4K@24/30Hz, 4K@50/60Hz

Limited Warranty

  • 1 Year Parts and Labor

Operating Temperature

  • 0℃ to 60℃

Storage Humidity

  • 5% to 90% RH non-condensation

Power Supply

  • N/A

Power Consumption (Max)

  • 5W

Splitter Unit Cert

  • FCC, CE, RoHS

Power Supply Cert

  • FCC, CE, RoHS

Power Adapter Standard

  • US, EU, UK, AU Standard etc.

Dimension(LxWxH)

  • 56x65x12.5mm

Net Weight

  • 56g

Material

  • Aluminium Alloy + ABS

User Manual

  • English Version

Note: Specifications are subject to change without notice.
